Devinci Django Carbon XT 12S LTD
Light, lively Split-Pivot Django brings unstoppable stoke to a tangle of trail types. This capable short-travel machine shines on climbs, while bringing adept handling to gnarled, technical turf. Superboost 157 rear spacing combined with 29x2.6 tire clearance accentuate its punchy, aggressive powers on rolling terrain. Relocated adjustable geo flip chips mean less moving parts and simple on-the-fly adjustability. And threaded BBs make for easy maintenance, while molded chainstay and downtube protection helps buck rocks and loose debris. Jump on the fun-hogging Django 29 today and find your happy place — everywhere you ride.
TECHNICAL
SPECIFICATIONS
DJANGO CARBON XT 12S LTD
Manufacturing
Designed & Assembled in Canada
Frame
- FRAMECarbon DMC-G 120mm
- HEADSETFSA Orbit | 1.5 | Zero Stack
- SEAT CLAMPAlloy CNC | 37mm
Suspension
- SUSPENSION FORKFox 36 Performance Elite Grip2 140 | 44 Offset
- REAR SHOCKFox Float DPS Performance Elite | 0.8VSpacer | 190x45
Cockpit
- HANDLEBARRaceFace Next R35 | B:35mm | R:20mm | W:800mm
- STEMRaceFace Turbine R35 | B:35mm | L:50mm | 0°
- SADDLESDG BELAIR 3.0
- SEATPOSTSDG Tellis 31.6mm | Travel 100mm
- SEATPOST LEVERSDG Tellis | I-Spec EV | 1x Lever
- GRIPSDevinci Performance | w/lock-on
Brakes
- FRONT BRAKEShimano XT M8120/M8100 | 4 Pistons
- REAR BRAKEShimano XT M8120/M8100 | 4 Pistons
- ROTORSShimano RT76 | 203mm
Drivetrain
- REAR DERAILLEURShimano XT M8100 | 12s
- REAR SHIFTERShimano XT M8100 | 12s | I-spec EV
- CRANKSETShimano XT M8130-1 | 32T | SuperBoost 157
- BOTTOM BRACKETShimano MT801 | BSA | 68/73mm
- CASSETTEShimano XT M8100 | 12s | 10-51T | Microspline
- CHAINShimano M7100 | 12s
Wheels
- FRONT RIMRaceFace ARC30 | 30mm inner | TR
- FRONT HUBRaceFace Vault | 6bolts | TA 15x110mm
- REAR HUBRaceFace Vault | 6bolts | TA 12x157mm | Microspline
- SPOKESSapim Stainless 14G w/Nylok
- FRONT TIREMaxxis Minion DHF | 29x2.5wt | 3C MaxxTerra Exo+ TR
- REAR TIREMaxxis Minion DHRII | 29x2.4wt | 3C MaxxTerra Exo+ TR
Weight
14.30 kg / 31.53 lb
*For a size medium complete bike, weight approximate and subject to change.
Bike Specifications are subject to change without notice. Specifications may not be exactly as shown in photo.
